PBT 605

Short Description:

Product Detail

Send Message

PBT it is one of the advanced engineering plastics with high rigidity, high toughness, good fatigue resistance, weather resistance, low water absorption rate (all the properties maintain under moisture atmosphere including electrical properties), high dielectric ability, good electrical capacity, size stability, good formability, excellent anti-creep ability under high impact, and good chemical properties as well. It is easy to process into glass-fiber reinforced and flame-retardant products. PBT/PET can be ultrasonic welded and easily post-processed.



●High toughness, high modulus, low creep

●Good dielectric strength

●Good dimensional stability

●Low water absorption rate, good hydrolysis resistance

●Good heat resistance, low coefficient of thermal expansion

●High impact strength

●Resistance to Thermal aging

●Easy to process


PBT 605
Flame-retardant Polybutylene Terephthalate

Characteristics

Meet the environmental standards of RoHS and IEC, high gloss, UL94 V-0 flame retardant,good light shading and ageing resistance.

Applications

Plug in fluorescent light, electrical equipment shell, etc.

Properties (23℃)

Typical Value[1]

Unit

Test Method

Mechanical

Tensile Stress

52

MPa

ISO 527

Tensile Strain

8

%

ISO 527

Flexural Stress

88

MPa

ISO 178

Flexural Modulus

3000

MPa

ISO 178

Izod Impact Strength

(Notched)

6

kJ/m2

ISO 180

Other

Density

1.47

g/cm3

ISO 1183

Volume Resistivity

1E14

Ohms·cm

IEC 60093

Flammability

V-0

Class

UL-94

Whiteness

95

-

-

Mold Shrinkage

1.5-1.9

%

ISO 294

Molding Process[2]

Drying Condition

Temperature

120-140℃

Time

2-4h

Mold Temperature

120℃

Barrel Temperature

Nozzle

Front

Middle

Rear

240-260 ℃

230-260 ℃

230-250 ℃

220-240 ℃

Note

[1] These figures are only intended as a guide and should not be used in preparing specifications.
[2] The molding process is only for reference and can be adjusted according to different models and products.
